The AYP-S3-TZ-3P intelligent miniature circuit breaker is suitable for indoor, AC 50Hz, rated voltage 220V, rated current no more than 80A, industrial, commercial, civil buildings and infrastructure in buildings and similar places, providing isolation protection for low-voltage terminal distribution. It can also be used for infrequent on/off operations.
| Poles No. | Type | Current level | Product model | width | Weight g |
| 3P | C | 32 | AYP-S3-TZC32 | 70.4mm (4P) | 560 |
| 63 | AYP-S3-TZC63 |
| 80 | AYP-S3-TZC80 |
| D | 32 | AYP-S3-TZD32 |
| 63 | AYP-S3-TZD63 |
| 80 | AYP-S3-TZD80 |
| 4P | C | 32 | AYP-S3-TNG32 | 88mm ( 5P) | 630 |
| 63 | AYP-S3-TNC63 |
| 80 | AYP-S3-TNC80 |
| D | 32 | AYP-S3-TND32 |
| 63 | AYP-S3-TND63 |
| 80 | AYP-S3-TND80 |
