ZW32-12 outdoor vacuum circuit breaker

The ZW32-12 outdoor vacuum circuit breaker (hereinafter referred to as the circuit breaker) is an outdoor power distribution equipment with a rated voltage of 12kV and a three-phase AC 50/60Hz. Mainly used for breaking and closing the load current, overload current and short circuit current in the power system. It is suitable for protection and control in power distribution systems of substations and industrial and mining enterprises, and places where rural power grids are frequently operated.

0771-3860772

products detial

What we can do ? different country different requirement all we can offer.

Mid-voltage ( kV)

3.6~35kv

(E.g. 35,33,24,22,20,18,15.75,13.8,13.2,12,11,10.5,10,7.2,6.6,6.3,6 etc.)

To Low voltage ( V)

100-660V

(E.g. 100,110,115,120,127,208,200,220,230,240,346,380,400,410,415,440,480,660 etc.)

Frequency (HZ)

50Hz or 60Hz

ZW32-12 outdoor vacuum circuit breaker

I. Overview

This circuit breaker has the characteristics of small size, light weight, anti-condensation, maintenance-free, etc., and can adapt to harsher climatic conditions and dirty environments.

II. Model and description

ZW 32-12/T630-20 G-port

口-S hand exercise. D electric exercise

G-band isolation

20-Rated short-circuit breaking current (kA)

630-rated current (A)

T-Bouncing Mechanism

12-Rated voltage (kV)

32-Design serial number

ZW-Outdoor Vacuum Circuit Breaker

Ⅲ.Specification

No.	Name	Unit	Data
1	Rated voltage	Kv	12
2	Rated frequency	Hz	50
3	Rated current	A	630
4	Rated short-circuit open current	KA	20
5	Rated peak tolerance current (peak)	KA	50
6	Rated short-time tolerated current	KA	20
7	Rated short-circuit turn-off current (peak)	KA	50
8	Mechanical life	time	10000
9	Rated short circuit open current open times	time	30
10	Power frequency withstand voltage(1min):( Wet(Dry)Alternatively, to the ground/ fracture	KV	42/48
11	Lightning impact withstand voltage (peak) alternate、to the ground/ fracture	KV	75/85
12	Secondary circuit 1min Workfrequency pressure resistance	KV	2
